Acoustical Specifications
Amplitude linearity (± 3 dB)120 Hz - 20000 Hz
Operating frequency range (-6 dB)100 Hz - 20000 Hz
Cut-off frequencies (-10 dB)95 Hz - 20000 Hz
Number of ways2
Sensitivity90 dB
Maximum SPL112 dB
Horizontal coverage100°
Vertical coverage100°
Technical Specifications
Nominal impedance8 Ω
AES power handling100 W
Program power handling200 W
Peak power handling300 W
Transducer (LF)1 x 4"
Transducer (HF)1 x 0.8"
Enclosure typeBass-Reflex
Crossover typePassive
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height188.0 mm
Width125.0 mm
Depth150.0 mm
Weight2.0 kg
Rigging4 x M5 threaded inserts for optional U-Brackets
Rigging2 x M5 threaded inserts for optional mounting adapter
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
