Acoustical Specifications
Amplitude linearity (± 3 dB)84 Hz - 20000 Hz
Operating frequency range (-6 dB)73 Hz - 20000 Hz
Cut-off frequencies (-10 dB)65 Hz - 20000 Hz
Number of ways2
Sensitivity97 dB
Maximum SPL123 dB
Horizontal coverage100°
Vertical coverage100°
Technical Specifications
Nominal impedance8 Ω
AES power handling250 W
Program power handling500 W
Peak power handling800 W
Transducer (LF)1 x 8"
Transducer (HF)1 x 1.7"
Enclosure typeBass-Reflex
Crossover typePassive
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height436.0 mm
Width266.0 mm
Depth311.0 mm
Weight11.0 kg
Handles2
Rigging4 x M8 threaded inserts for optional U-Brackets
Rigging2 x M8 threaded inserts for optional mounting adapters
Rigging4 x M8 threaded inserts for optional wall mounts
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
