Acoustical Specifications
Amplitude linearity (± 3 dB)43 Hz - 350 Hz
Operating frequency range (-6 dB)40 Hz - 350 Hz
Cut-off frequencies (-10 dB)36 Hz - 350 Hz
Number of ways1
Sensitivity92 dB
Maximum SPL118 dB
Horizontal coverage360°
Vertical coverage360°
Technical Specifications
Nominal impedance8 Ω
AES power handling300 W
Program power handling600 W
Peak power handling1200 W
Transducer (LF)1 x 8''
Enclosure typeBass-Reflex
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height690.0 mm
Width320.0 mm
Depth190.0 mm
Weight20.0 kg
Handles2
Rigging8 x M8 threaded inserts for optional U-Brackets
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
