Acoustical Specifications
Amplitude linearity (± 3 dB)43 Hz - 350 Hz
Operating frequency range (-6 dB)38 Hz - 350 Hz
Cut-off frequencies (-10 dB)33 Hz - 350 Hz
Number of ways2
Sensitivity99 dB
Maximum SPL129 dB
Horizontal coverage360°
Vertical coverage360°
Technical Specifications
Nominal impedance8 Ω
AES power handling1000 W
Program power handling2000 W
Peak power handling2800 W
Transducer (LF)1 x 15"
Enclosure typeBass-Reflex
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height466.0 mm
Width462.0 mm
Depth600.0 mm
Weight32.0 kg
Rigging4 x M8 threaded inserts for optional U-Bracket
Rigging1 x screw receptacle for satellite pole
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
