Acoustical Specifications

Amplitude linearity (± 3 dB)32 Hz - 350 Hz
Operating frequency range (-6 dB)30 Hz - 350 Hz
Cut-off frequencies (-10 dB)28 Hz - 350 Hz
Number of ways1
Sensitivity104 dB
Maximum SPL141 dB
Horizontal coverage360°
Vertical coverage360°

Technical Specifications

Nominal impedance4 Ω
AES power handling2000 W
Program power handling4000 W
Peak power handling5600 W
Transducer (LF)2 x 18"
Enclosure typeBass-Reflex

Connector and Button Specifications

Input connectors (Analog)2 x speakON NL4MP

Physical Specifications

Height770.0 mm
Width1000.0 mm
Depth650.0 mm
Weight83.0 kg
Handles6
Rigging1 x screw receptacle for satellite pole
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
