Acoustical Specifications
Amplitude linearity (± 3 dB)51 Hz - 350 Hz
Operating frequency range (-6 dB)46 Hz - 350 Hz
Cut-off frequencies (-10 dB)41 Hz - 350 Hz
Number of ways1
Sensitivity92 dB
Maximum SPL118 dB
Horizontal coverage360°
Vertical coverage360°
Technical Specifications
Nominal impedance8 Ω
AES power handling300 W
Program power handling600 W
Peak power handling650 W
Transducer (LF)1 x 8"
Enclosure typeBass-Reflex
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height334.0 mm
Width310.0 mm
Depth370.0 mm
Weight15.0 kg
Handles2
Rigging4 x M8 threaded inserts for optional U-Bracket
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
