Acoustical Specifications
Amplitude linearity (± 3 dB)75 Hz - 20000 Hz
Operating frequency range (-6 dB)65 Hz - 20000 Hz
Cut-off frequencies (-10 dB)59 Hz - 20000 Hz
Number of ways3
Sensitivity LF97 dB
Sensitivity MHF112 dB
Maximum SPL LF130 dB
Maximum SPL MHF142 dB
Horizontal coverage100°
Vertical coverage10°
Technical Specifications
Nominal impedance LF16 Ω
Nominal impedance MHF16 Ω
AES power handling LF700 W
AES power handling MHF150 W
Peak power handling LF1200 W
Peak power handling MHF1000 W
Transducer (LF)1 x 8"
Transducer (MF)1 x 3.5"
Transducer (HF)1 x 1.75"
Enclosure typeBass-Reflex
Crossover typeActive (FIR)
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height230.0 mm
Width589.0 mm
Depth459.0 mm
Weight21.0 kg
RiggingCompatible with DIVA BUMP M² and DIVA BUMP M² MINI
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
