| Acoustical Specifications | Amplitude Linearity:52 Hz - 350 Hz Operating Frequency Range:45 Hz - 350 Hz Cut-off Frequencies:40 Hz - 350 Hz Number of Ways:1 Sensitivity (LMHF, 8Ω):97 dB Maximum SPL (LMHF):127 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:900 W Program Power Handling:1800 W Peak Power Handling:2000 W Transducer LF:1 x 12’’ driver with neodymium magnet Enclosure Type:Passive Radiator (1x 12") |
| Connector Specifications | Analog:1 x speakON NL4MP |
| Physical Specifications | Height:388 mm Width:388 mm Depth:333 mm Weight:13.1 kg Handles:2 Rigging:2 x M8 threaded inserts for optional U-Bracket Rigging:2 x M8 threaded inserts for optional mounting adapter |
