| Acoustical Specifications | Amplitude Linearity:43 Hz - 350 Hz Operating Frequency Range:40 Hz - 350 Hz Cut-off Frequencies:36 Hz - 350 Hz Number of Ways:1 Sensitivity (LF, 8Ω):92 dB Maximum SPL (LF):118 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:300 W Program Power Handling:600 W Peak Power Handling:1200 W Transducer LF:1 x 8'' Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:690 mm Width:320 mm Depth:190 mm Weight:20 kg Handles:2 Rigging:8 x M8 threaded inserts for optional U-Brackets |
