| Acoustical Specifications | Amplitude Linearity:43 Hz - 350 Hz Operating Frequency Range:38 Hz - 350 Hz Cut-off Frequencies:33 Hz - 350 Hz Number of Ways:1 Sensitivity (LF, 8Ω):99 dB Maximum SPL (LF):129 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:1000 W Program Power Handling:2000 W Peak Power Handling:2800 W Transducer LF:1 x 15" Enclosure Type:Bass-Reflex Crossover Type:Active |
| Loudspeaker Processing | Crossover:Multiple filter types (Butterworth, Linkwitz-Riley, Bell, High Shelf, Low Shelf, Notch, All Pass, Band Pass, High Pass, Low Pass) up to 24 dB / Oct. Control & Monitoring Interface:Full configuration and real-time monitoring via PC, Mac and iPad |
| Connector Specifications | Analog:1 x Male XLR (Pin 2+, Pin 3-), 1 x Female XLR (Pin 2+, Pin 3-) AES/EBU:1 x Male XLR (Pin 2+, Pin 3-), 1 x Female XLR (Pin 2+, Pin 3-) Dante:2 x RJ45 etherCON Mains Connectors:1 x IEC 16 A Buttons:Power, Up, Down Encoder:Adjust, Set |
| Physical Specifications | Height:466 mm Width:462 mm Depth:698 mm Weight:40 kg Handles:2 Rigging:4 x M8 threaded inserts for optional U-Bracket Rigging:1 x screw receptacle for satellite pole |
