| Acoustical Specifications | Amplitude Linearity:35 Hz - 350 Hz Operating Frequency Range:30 Hz - 350 Hz Cut-off Frequencies:26 Hz - 350 Hz Number of Ways:1 Sensitivity (LF, 8Ω):98 dB Maximum SPL (LF):134 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:1700 W Program Power Handling:3400 W Peak Power Handling:5000 W Transducer LF:1 x 18" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:900 mm Width:565 mm Depth:450 mm Weight:43 kg Handles:2 Rigging:8 x M8 threaded inserts for optional U-Brackets |
