| Acoustical Specifications | Amplitude Linearity:43 Hz - 350 Hz Operating Frequency Range:38 Hz - 350 Hz Cut-off Frequencies:33 Hz - 350 Hz Number of Ways:1 Sensitivity (LF, 8Ω):99 dB Maximum SPL (LF):129 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:1000 W Program Power Handling:2000 W Peak Power Handling:2800 W Transducer LF:1 x 15" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:466 mm Width:462 mm Depth:600 mm Weight:32 kg Handles:2 Rigging:4 x M8 threaded inserts for optional U-Bracket Rigging:1 x screw receptacle for satellite pole |
