| Acoustical Specifications | Frequency Response (± 3 dB):32 Hz - 350 Hz Operating Frequency Range (-6 dB):30 Hz - 350 Hz Cut-off Frequencies (-10 dB):28 Hz - 350 Hz Number of Ways:1 Sensitivity (4 Ω):104 dB Maximum SPL:141 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:4 Ω AES Power Handling:2000 W Program Power Handling:4000 W Peak Power Handling:5600 W Transducer LF:2 x 18" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:770 mm Width:1000 mm Depth:650 mm Weight:83 kg Handles:6 Rigging:1 x screw receptacle for satellite pole |
