| Acoustical Specifications | Amplitude Linearity:32 Hz - 250 Hz Operating Frequency Range:29 Hz - 250 Hz Cut-off Frequencies:26 Hz - 250 Hz Number of Ways:1 Maximum SPL (LF):147 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:4 Ω AES Power Handling:2000 W Program Power Handling:4000 W Peak Power Handling:5600 W Transducer LF:2 x 15" Enclosure Type:Folded Waveguide |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:1350 mm Width:625 mm Depth:1250 mm Weight:103 kg Handles:10 |
