| Acoustical Specifications | Frequency Response (± 3 dB):41 Hz - 350 Hz Operating Frequency Range (-6 dB):38 Hz - 350 Hz Cut-off Frequencies (-10 dB):33 Hz - 350 Hz Number of Ways:1 Sensitivity (8 Ω):99 dB Maximum SPL:129 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:1000 W Program Power Handling:2000 W Peak Power Handling:2800 W Transducer LF:1 x 15" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:800 mm Width:500 mm Depth:340 mm Weight:33 kg Handles:2 Rigging:8 x M8 threaded inserts for optional U-Brackets |
