| Acoustical Specifications | Frequency Response (± 3 dB):43 Hz - 350 Hz Operating Frequency Range (-6 dB):40 Hz - 350 Hz Cut-off Frequencies (-10 dB):38 Hz - 350 Hz Number of Ways:1 Sensitivity (8 Ω):97 dB Maximum SPL:127 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:900 W Program Power Handling:1800 W Peak Power Handling:2500 W Transducer LF:1 x 12" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:796 mm Width:388 mm Depth:290 mm Weight:30 kg Handles:2 Rigging:8 x M8 threaded inserts for optional U-Brackets |
