C 6
Ultra-compact 2-way passive loudspeaker with 90° axisymmetric dispersion (1 x 6’’ LF ; 1 x 1’’ HF)
| Acoustical Specifications | Frequency Response (± 3 dB):93 Hz - 20000 Hz Operating Frequency Range (-6 dB):84 Hz - 20000 Hz Cut-off Frequencies (-10 dB):78 Hz - 20000 Hz Number of Ways:2 Sensitivity (8 Ω):93 dB Maximum SPL:118 dB Horizontal Coverage:90° Vertical Coverage:90° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:170 W Program Power Handling:240 W Peak Power Handling:360 W Transducer LF:1 x 6.5’’ driver Transducer HF:1 x 1’’ neodynium compression driver Enclosure Type:Bass-Reflex Crossover Type:Passive |
| Connector Specifications | Power Connector:1 x speakON NL4MP |
| Physical Specifications | Height:274 mm Width:274 mm Depth:186 mm Weight:5.3 kg Rigging:2 x M6 threaded inserts for optional U-Bracket Rigging:2 x M8 threaded inserts for optional mounting adapter |
