| Acoustical Specifications | Frequency Response (± 3 dB):51 Hz - 350 Hz Operating Frequency Range (-6 dB):46 Hz - 350 Hz Cut-off Frequencies (-10 dB):41 Hz - 350 Hz Number of Ways:1 Sensitivity (8 Ω):92 dB Maximum SPL:118 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:300 W Program Power Handling:600 W Peak Power Handling:650 W Transducer LF:1 x 8" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:334 mm Width:310 mm Depth:370 mm Weight:15 kg Handles:2 Rigging:4 x M8 threaded inserts for optional U-Bracket |
