| Acoustical Specifications | Frequency Response (± 3 dB):45 Hz - 350 Hz Operating Frequency Range (-6 dB):40 Hz - 350 Hz Cut-off Frequencies (-10 dB):35 Hz - 350 Hz Number of Ways:1 Sensitivity (8 Ω):97 dB Maximum SPL:127 dB Horizontal Coverage:360° Vertical Coverage:360° |
| Technical Specifications | Nominal Impedance:8 Ω AES Power Handling:900 W Program Power Handling:1800 W Peak Power Handling:2500 W Transducer LF:1 x 12" Enclosure Type:Bass-Reflex |
| Connector Specifications | Analog:2 x speakON NL4MP |
| Physical Specifications | Height:415 mm Width:388 mm Depth:450 mm Weight:20 kg Handles:2 Rigging:4 x M8 threaded inserts for optional U-Bracket Rigging:1 x screw receptacle for satellite pole |
