Acoustical Specifications

Amplitude linearity (± 3 dB)78 Hz - 20000 Hz
Operating frequency range (-6 dB)70 Hz - 20000 Hz
Cut-off frequencies (-10 dB)62 Hz - 20000 Hz
Number of ways2
Sensitivity98 dB
Maximum SPL131 dB
Horizontal coverage80°
Vertical coverage60°

Technical Specifications

Nominal impedance8 Ω
AES power handling500 W
Program power handling1000 W
Peak power handling2000 W
Transducer (LF)1 x 12"
Transducer (HF)1 x 1.75"
Enclosure typeBass-Reflex
Crossover typePassive

Connector and Button Specifications

Input connectors (Analog)1 x speakON NL4MP

Physical Specifications

Height388.0 mm
Width388.0 mm
Depth265.0 mm
Weight14.0 kg
Handles2
Rigging4 x M8 threaded inserts for optional U-Bracket
Rigging2 x M8 threaded inserts for optional mounting adapter
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
