C 4
Learn more
| Acoustical Specifications | Amplitude linearity (± 3 dB): 90 Hz - 20000 Hz Operating frequency range (-6 dB): 75 Hz - 20000 Hz Cut-off frequencies (-10 dB): 70 Hz - 20000 Hz Number of ways: 2 Sensitivity: 83 dB Maximum SPL: 105 dB Horizontal coverage: 90° Vertical coverage: 90° |
| Technical Specifications | Nominal impedance: 8 Ω AES power handling: 30 W Program power handling: 60 W Peak power handling: 120 W Transducer (LF): 1 x 4" Transducer (HF): 1 x 0.75" Enclosure type: Sealed Crossover type: Passive |
| Connector and Button Specifications | Input connectors (Analog): 1 x speakON NL4MP or 1 x Binding Post or 1 x Cable Gland |
| Physical Specifications | Height: 180.0 mm Width: 180.0 mm Depth: 127.0 mm Weight: 2.0 kg Rigging: 2 x M5 threaded inserts for optional U-Bracket Standard colour codes for cabinet: 9005/9010/1013/7040/7030/5011 Standard colour codes for fabric: 9005/9006/9010/1035/1036 |
