Acoustical Specifications
Amplitude linearity (± 3 dB)65 Hz - 20000 Hz
Operating frequency range (-6 dB)60 Hz - 20000 Hz
Cut-off frequencies (-10 dB)55 Hz - 20000 Hz
Number of ways2
Sensitivity95.5 dB
Maximum SPL116 dB
Horizontal coverage90°
Vertical coverage90°
Technical Specifications
Nominal impedance8 Ω
AES power handling200 W
Program power handling400 W
Peak power handling600 W
Transducer (LF)1 x 8"
Transducer (HF)1 x 1.75"
Enclosure typeBass-Reflex
Crossover typePassive
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height245.0 mm
Width391.0 mm
Depth318.0 mm
Weight9.0 kg
Handles2
Rigging8 x M6 threaded inserts for optional flying brackets
Rigging1 x 35 mm pole socket
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
