CX 15 R

CX 15 R

Learn more

Acoustical Specifications
Amplitude linearity (± 3 dB)61 Hz - 20000 Hz
Operating frequency range (-6 dB)57 Hz - 20000 Hz
Cut-off frequencies (-10 dB)53 Hz - 20000 Hz
Number of ways2
Sensitivity98 dB
Horizontal coverage60°
Vertical coverage80°
Technical Specifications
Nominal impedance8 Ω
AES power handling500 W
Program power handling1000 W
Peak power handling2000 W
Transducer (LF)1 x 15"
Transducer (HF)1 x 1.75"
Enclosure typeBass-Reflex
Crossover typePassive
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height491.0 mm
Width580.0 mm
Depth352.0 mm
Weight24.0 kg
Handles2
Rigging8 x M8 threaded inserts for optional flying brackets
Rigging1 x 35 mm pole socket
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
