Acoustical Specifications
Amplitude linearity (± 3 dB)52 Hz - 350 Hz
Operating frequency range (-6 dB)45 Hz - 350 Hz
Cut-off frequencies (-10 dB)40 Hz - 350 Hz
Number of ways1
Sensitivity97 dB
Maximum SPL127 dB
Horizontal coverage360°
Vertical coverage360°
Technical Specifications
Nominal impedance8 Ω
AES power handling900 W
Program power handling1800 W
Peak power handling2000 W
Transducer (LF)1 x 12"
Enclosure typePassive Radiator (1 x 12")
Connector and Button Specifications
Input connectors (Analog)1 x speakON NL4MP
Physical Specifications
Height388.0 mm
Width388.0 mm
Depth333.0 mm
Weight13.0 kg
Handles2
Rigging2 x M8 threaded inserts for optional U-Bracket
Rigging2 x M8 threaded inserts for optional mounting adapter
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
Standard colour codes for fabric9005/9006/9010/1035/1036
