Acoustical Specifications
Amplitude linearity (± 3 dB)32 Hz - 250 Hz
Operating frequency range (-6 dB)29 Hz - 250 Hz
Cut-off frequencies (-10 dB)26 Hz - 250 Hz
Number of ways1
Sensitivity112 dB
Maximum SPL147 dB
Horizontal coverage360°
Vertical coverage360°
Technical Specifications
Nominal impedance4 Ω
AES power handling2000 W
Program power handling4000 W
Peak power handling5600 W
Transducer (LF)2 x 15"
Enclosure typeFolded Waveguide
Connector and Button Specifications
Input connectors (Analog)2 x speakON NL4MP
Physical Specifications
Height1350.0 mm
Width625.0 mm
Depth1250.0 mm
Weight103.0 kg
Standard colour codes for cabinet9005/9010/1013/7040/7030/5011
